Capsulated Spring Seal
Seal Type- HJV-1010
The Type HJV-1010 is capsulated balance seal designed for
media containing solid slurry particles. The springs are protected
from solidifying media resulting in high reliability of the seal.This
seals are independent of direction of rotation.
Product Features :
- Single Acting
- Capsulated Spring
- Independent of Direction of Rotation
Applications :
- General Chemicals
- Media Containing solids particles
- Acids & Alkalies
Material of Constructions:
| Seal body | Seal Faces | Springs | Elastomers |
|---|---|---|---|
|
AISI 316, Alloy-20,
Hastelloy C |
Carbon, Silicon Carbide,
Ceramic (99.5%),
PTFE, GFT, CFT
|
AISI 316, Alloy-20,
Hastelloy C |
Viton, EPDM, TTV, FEP.
Aflas, Kalrez
|
Operating Limits:
| Pressure | Temperature | Shaft Dia |
|---|---|---|
|
upto 6 Bar |
-20°C to +100°C |
18mm to 100mm |
